The Best External Antennas For the Verizon Jetpack MiFi 8800L
Using a MIMO antenna outside your building, pointed at the nearest tower, can help you get the fastest LTE data rates possible.
The Verizon Jetpack 8800L has two TS9 ports on the bottom, covered by little grey caps. These allow for a 2x2 MIMO antenna to be connected to the device.
We recommend two different MIMO antenna options for use with the Verizon Jetpack MiFi 8800L:
This MIMO panel antenna kit will provide meaningful signal improvement, even if you're surrounded by trees, hills, or tall buildings.
For most users the best external antenna choice for the Verizon Jetpack MiFi 8800L is our 2x2 MIMO panel antenna kit. This antenna doesn’t require line-of-sight to the tower.
These cross polarized log periodic antennas are have higher gain and are more directional, but work best if you have direct line-of-sight to the tower.
However, if you have line of sight to the nearest tower, we recommend using a 2x2 MIMO log periodic antenna kit instead. The higher gain on these antennas can get you better performance, but only when you have a straight shot to the tower.
Why External Antennas Are Critical for Improving Data Rates
Most people think that external antennas primarily help you increase your data rates by increasing the signal strength.But that's not the case.
An increase in signal strength is often less important than other ways that external antennas help.
Here are the three main ways that external antennas help you increase your data rates:
1.They Improve Signal Quality
In 4G LTE networks, signal quality is measured as SINR (Signal to Interference plus Noise Ratio) or sometimes as RSRQ (Reference Signal Received Quality).
Improving signal quality has a huge impact on your data rates.
Higher data rates allow your hotspot to communicate using "higher order modulation schemes." That means they can use the same wireless spectrum to send more data per second.
However, there's one big caveat:
In order to improve your signal quality, you need to both aim and shield your outdoor antenna properly. We talk more about this in the next section.
2.They Allow You To Connect On More Bands
Hotspots like the Jetpack 8800L support an LTE feature called "carrier aggregation."
Carrier aggregation allows the Jetpack 8800L to connect on multiple cellular bands simultaneously.
The more bands you're connected on, the greater the bandwidth, and the higher your data rates.
However, many of the higher frequency bands aren't able to penetrate into buildings. Using external antennas allows you to access higher frequency bands, which are often less congested and offer higher speeds than lower frequency bands.
3.MIMO Isolation
MIMO (Multiple Input Multiple Output) technology uses signals travelling along multiple paths simultaneously, increasing both bandwidth and reliability in wireless connections.
MIMO isolation is the antenna's ability to handle several data streams at once, cleanly and without interference, leading to quicker data speeds and steadier connections
Our external antennas are specifically designed for superior MIMO isolation, and dramatically outperform standard built-in antennas found in most home devices.
This means you'll see a more reliable connection with enhanced bandwidth, ensuring smoother streaming, gaming, and browsing with minimal interruptions.
Positioning and Aiming MIMO Antennas
Positioning and aiming MIMO antennas well is crucial to getting the best performance to your Verizon Jetpack MiFi 8800L, or indeed any other hotspot.
We've actually compiled a detailed instruction manual to accompany our own MIMO Antenna Kits, where we go into depth on the best ways to aim the antennas.
The goal is to find the best location and direction for the antenna(s), to maximize data rates to the Jetpack. It can take a little patience, but can have a huge impact – it’s worth a bit of extra effort!
Before getting started, it's always a good idea to run a couple of speed tests indoors from a device connected to your Jetpack's WiFi. The results will fluctuate a little, but this is the baseline you're trying to improve.
TS9 adapters connected to the Verizon Jetpack 8800L
Now connect the MIMO antennas to your Verizon Jetpack MiFi 8800L via the TS-9 ports, and go outside with your "test-rig".
With each location and direction you try, run a couple speed tests, and make a note of the results. Here are all the locations and directions where we recommend testing your MIMO antenna:
Where to test your signal
Pro tip: Don’t just go to the highest point of the roof! While signal is generally stronger the higher you go, there’s also often more interference. We’ve found it’s often better to mount the antenna(s) on the side of the building where the structure can shield the antennas from interference.
Once you've found the position which gets you the highest data rates to the Jetpack, that's where you'll want to install the MIMO antenna. Go ahead and mount the antenna, run cables inside, connect everything up, and enjoy superior data rates!
